KILE-2
192 Single Fiber (8 pcs Splice Tray ) |
 |
 |
 |
KILE-2
provide with 4 fiber cable in-out round ports and the cable diameter
is from ?10-?22. It can be used in aerial, duct, and direct buried
application. This product is made from the high-quality and with the
mechanical sealing structure filled with the sealing material. The
external component and fastening piece are all made from the
high-quality stainless steel. It can be opened after sealing.
Available
for Underground, Aerial
| Item |
KILE-2 |
| Dimension (MM) |
435×190×85 |
| Weight (Kg) |
2.8 |
| Cable diameter (MM) |
ø 10-ø 22 |
| Cable entry ports |
two cable entry port on each end |
| Max Capacity of Fiber Splice |
24 (single) |
| Max Capacity of Splice Tray |
8 |
| Max Capacity |
192(single) |
| Sealing structure |
Sticky cincture |
Pack Information
| Products dimension(mm) |
Products |
Package dimension for out side carton
(mm) |
No of units per carton(pcs) |
Total weight(kg) |
| weight(kg) |
| 496*196*138 |
2.8 |
515*425*575 |
8 |
23.8 |
|
 |
|
KILE-3
288 single fiber (12 pcs Splice Tray ) |
|
KILE-3
provides with 8 fiber cable in-out round ports and the cable
diameter is from ?10-?22. It can be used in aerial, duct and direct
buried application. The product is made from the high-quality with
the mechanical sealing structure filled with the sealing material.
The external component and fastening piece are all made from the
high-quality stainless steel. It can be opened after sealing.
Available
for Underground, Aerial
| Item |
KILE-3 |
| Dimension (mm) |
435×190×170 |
| Weight (Kg) |
4.7 |
| Cable diameter (MM) |
ø 10-ø 22 |
| Cable entry ports |
Four cable entry port on each end |
| Max Capacity of Fiber Splice |
24 (single) |
| Max Capacity of Splice Tray |
12 |
| Max Capacity |
288(single) |
| Sealing structure |
Sticky cincture |
Pack information
| Products dimension(mm) |
Products |
Package dimension for out side carton
(mm) |
No of units per carton(pcs) |
Total weight(kg) |
| weight(kg) |
| 496*196*180 |
4.7 |
515*425*575 |
6 |
30 |
|
 |
|
KILE-4
Single Fiber (4 pcs Splice Tray ) |
|
|
 |
The
KILE-4 FOSC is configured with two pairs of in-out ports. It is used
in aerial, direct or branch connections. It is easy to install due
to the four sliding in and lock plate. The inner parts are made of
quality engineering plastic and sealing materials. The cover is made
of stainless steel. So it is applicable under extreme climates. This
product can be reopened repeatedly after being sealed.
Available
for Underground, Aerial
| Item |
KILE-4 |
| Dimension (mm) |
485(440)×165×110 |
| Weight(Kg) |
2.45 |
| Diameter of Cable(mm) |
ø 10-ø 22 |
| No. of Cable Inlet/Outlet |
Four |
| Number of Fibers per Tray |
24(single core) |
| Max. Number of Trays |
4 |
| Max. Number of Fibers |
96(single core) |
| Sealing of Shells |
Self-adhesive tape |
Pack information
| Products dimension(mm) |
Products |
Package dimension for out side carton
(mm) |
No of units per carton(pcs) |
Total weight(kg) |
| weight(kg) |
| 520*180*120 |
2.45 |
540*405*515 |
8 |
21.1 |
|
|
|
KILE-5
single fiber (8 pcs Splice Tray ) |
|
The
KILE-5 FOSC is configured with two pairs of in-out ports. It is used
in aerial, direct or branch connections. It is easy to install due
to the four sliding in and lock plate. The inner parts are made of
quality engineering plastic and sealing materials. The cover is made
of stainless steel. So it is applicable under extreme climates. This
product can be reopened repeatedly after being sealed.
Available
for Underground, Aerial
| Item |
KILE-5 |
| Dimension (MM) |
580(480)×185×125 |
| Weight (Kg) |
3.5 |
| Diameter of Cable(mm) |
ø10-ø 22 |
| No. of Cable Inlet/Outlet |
Four |
| Number of Fibers per Tray |
24(single core) |
| Max. Number of Trays |
8 |
| Max Capacity |
192(single core) |
| Sealing of Shells |
Self-adhesive tape |
Pack information
| Products dimension(mm) |
Products |
Package dimension for out side carton
(mm) |
No of units per carton(pcs) |
Total weight(kg) |
| weight(kg) |
| 580*220*125 |
3.5 |
605*435*410 |
6 |
22.5 |
|
 |
|
KILE-6
single fiber (8 pcs Splice Tray ) |
|
|
 |
The
KILE-6 FOSC is configured with two pairs of in-out ports. It is used
in aerial, direct or branch connections. It is easy to install due
to the four sliding in and lock plate. The inner parts are made of
quality engineering plastic and sealing materials. The cover is made
of stainless steel. So it is applicable under extreme climates. This
product can be reopened repeatedly after being sealed.
Available
for Underground, Aerial
| Item |
KILE-6 |
| Dimension (MM) |
655(550)×215×185 |
| Weight (Kg) |
5.6 |
| Diameter of Cable(mm) |
ø 10-ø 22 |
| No. of Cable Inlet/Outlet |
Four |
| Number of Fibers per Tray |
24(single core) |
| Max. Number of Trays |
8 |
| Max. Number of Fibers |
192(single core) |
| SSealing of Shells |
Self-adhesive tape |
Pack Information
| Products dimension(mm) |
Products |
Package dimension for out side carton
(mm) |
No of units per carton(pcs) |
Total weight(kg) |
| weight(kg) |
| 670*235*125 |
5.6 |
690*505*435 |
4 |
23.9 |
|
|
|
KILE-6D
single fiber (5 pcs Splice Tray ) |
|
The
KILE-6D FOSC is configured with two pairs of in-out ports. It is
used in aerial, direct or branch connections. It is easy to install
due to the four sliding in and lock plate. The inner parts are made
of quality engineering plastic and sealing materials. The cover is
made of stainless steel. So it is applicable under extreme climates.
This product can be reopened repeatedly after being sealed.
Available
for Underground, Aerial
| Item |
KILE-6D |
| Dimension (MM) |
655(550)×215×185 |
| Weight (Kg) |
5.6 |
| Diameter of Cable(mm) |
ø 10-ø 22 |
| No. of Cable Inlet/Outlet |
Four |
| Number of Fibers per Tray |
72(ribbon) |
| Max. Number of Trays |
5 |
| Max. Number of Fibers |
360(ribbon) |
| Sealing of Shells |
Self-adhesive tape |
Pack Information
| Products dimension(mm) |
Products |
Package dimension for out
side carton (mm) |
No of units per
carton(pcs) |
Total weight(kg) |
| weight(kg) |
| 670*235*220 |
5.6 |
690*505*435 |
4 |
23.9 |
|
 |
|
|
