KRMSP-19Ss
standard Structure |
 |
 |
 |
KRMSP
serial fiber terminal box can be applied in the branch connection of
fiber termination, work as distribution box ,19”standard
structure, rack mounting ,available for the installation of
FC,SC,ST,LC adaptors.
Order Guide
| Type |
Products Dimension(mm) |
Products |
Package dimension for out side carton (mm) |
No of units per carton(pcs) |
Total weight(kg) |
| |
|
weight(kg) |
|
|
|
| KRMSP -SC12 |
465*285*75 |
2.6 |
470*310*300 |
5 |
14.2 |
| KRMSP -SC24 |
465*285*75 |
|
470*310*300 |
|
|
| KRMSP -SC48 |
450*270*100 |
3.8 |
550*470*300 |
|
21 |
| KRMSP -FC12 |
465*285*75 |
2.6 |
470*310*300 |
|
14.2 |
| KRMSP -FC24 |
465*285*75 |
|
470*310*300 |
|
|
| KRMSP -FC48 |
450*270*100 |
3.8 |
550*470*300 |
|
21 |
| KRMSP -ST12 |
465*285*75 |
2.6 |
470*310*300 |
|
14.2 |
Pack Guide
| Type |
Products dimension(mm) |
Products |
Package dimension for out side carton (mm) |
No of units per carton(pcs) |
Total weight(kg) |
| |
|
weight(kg) |
|
|
|
| KRMSP -SC12 |
465*285*75 |
2.6 |
470*310*300 |
5 |
14.2 |
| KRMSP -SC24 |
465*285*75 |
|
470*310*300 |
|
|
| KRMSP -SC48 |
450*270*100 |
3.8 |
550*470*300 |
|
21 |
| KRMSP -FC12 |
465*285*75 |
2.6 |
470*310*300 |
|
14.2 |
| KRMSP -FC24 |
465*285*75 |
|
470*310*300 |
|
|
| KRMSP -FC48 |
450*270*100 |
3.8 |
550*470*300 |
|
21 |
| KRMSP -ST12 |
465*285*75 |
2.6 |
470*310*300 |
|
14.2 |
| KRMSP -ST24 |
465*285*75 |
|
470*310*300 |
|
|
|
 |
|
KPMSP-DDS
Dummy Drawer Structure |
|
KPMSP-DDS
Serial dummy drawer optical Fiber Terminal Box can be applied in the
branch connection of terminal optical fiber cables,19”standard
structure, rack mounting, available for the adaptors installation
such as FC,SC,ST,LC.
Order Guide
| Type |
Dimension(mm) |
Max Capacity (cores) |
Remark |
| KPMSP-DDS-SC24 |
430×300×1U |
24 |
The case body is made from cold rolled steel sheet,
available for adaptors installation such as FC,SC,ST,LC |
| KPMSP-DDS-FC24 |
430×300×1U |
24 |
|
| KPMSP-DDS-2SC12 |
430×300×1U |
24 |
|
| KPMSP-DDS-2SC24 |
430×300×1U |
48 |
|
Pack Information
| Type |
Products dimension(mm) |
Products |
Package dimension for out side carton (mm) |
No of units per carton(pcs) |
Total weight(kg) |
| |
|
weight(kg) |
|
|
|
| KPMSP-DDS |
465*330*75 |
3.3 |
485*400*350 |
5 |
18 |
|
 |
|
KPMSP-DRS
Drawer Structure |
|
|
 |
KPMSP-DRS
Serial drawer type Fiber Terminal Box can be applied in the branch
connection of optical cable termination, 19”standard structure,
rack mounting, available for the installation of FC?SC?ST?LC
adaptors.
Order Guide
| Model |
Dimension(mm) |
Mac capacity(cores) |
Remarks |
| KPMSP-DRS-SC12 |
430×300×1U |
12 |
The case body is made from cold rolled steel sheet, and the
surface use the technique of electrostatic spraying, available
for the installation of FC,SC,ST,LC adaptors |
| KPMSP-DRS -FC24 |
|
24 |
|
| KPMSP-DRS -2SC24 |
|
48 |
|
| KPMSP-DRS -FC48 |
430*300*2U |
48 |
|
Pack Guide
| Type |
Package dimension for inner carton |
Products |
Package dimension for out side carton (mm) |
No of units per carton(pcs) |
Total weight(kg) |
| |
|
weight(kg) |
|
|
|
| KPMSP-DRS -SC12 |
465*330*75 |
5.5 |
485*400*350 |
5 |
28.5 |
| KPMSP-DRS -FC24 |
|
|
|
|
|
| KPMSP-DRS -2SC24 |
|
|
|
|
|
| KPMSP-DRS -FC48 |
475*335*130 |
6.2 |
500*350*550 |
4 |
26 |
|
|
|
KPMSP-DUS
Dustproof Structure |
|
- KPMSP-DU serial optical fiber terminal box can be used for
the branch connection of optical cable ermination,19”
standard structure
- Available for the rack installation of adaptors for
FC?SC?ST?LC and so on.
- Dimension: 430×300×1U
- Material: cold rolled steel sheet
- Capacity: single core 24 double core 48
- Weight:3.9kg
Packing information
| Type |
Products dimension(mm) |
Products |
Package dimension for out side carton (mm) |
No of units per carton(pcs) |
Total weight(kg) |
| |
|
weight(kg) |
|
|
|
| KPZ/JJ-FCZ/2SC24 |
465*330*75 |
4.1 |
485*400*350 |
5 |
21.5 |
| KPZ/JJ-FCZ/X/2SC12 |
|
5 |
|
5 |
24.2 |
|
 |
|
KWMSB-D
distribution box with door 12-72fibers |
|
|
 |
- Available for small capacity communication system, wall
mounting, reasonable and compact structure, harmonized with
machine room.
- The cabinet is composed of two parts, one links with optical
cables for fusion connection between optical cable and fiber
pigtail and another links with patch cord.
- Provide fusion and storage appliance for optical cables.
- Reliable protection appliance of fixing, stripping and
earthing for optical cables.
- Whole range protected design for fiber lay to ensure the
bending radius >=40mm
- Provide various accessories to avoid any unexpected damage to
the fiber
Order Guide
| TYPE |
SIZE(mm) |
Max capacity |
Remark |
| KWMSB-D /A-24 |
455*405*80 |
24 |
The case body is made of cold rolled steel sheet,
electrostatic spraying, outdoor wall mounting, provide 24-72
adaptors, available for |
| KWMSB-D /A-48 |
455*405*120 |
48 |
SC\ST\LC |
| KWMSB-D /A-72 |
455*405*150 |
72 |
|
| KWMSB-D /B-48 |
455*405*120 |
48 |
The case body is made of stainless steel, electrostatic
spraying, outdoor wall mounting ,provide 48-72 adaptors
available for FC\SC\ST\LC |
| KWMSB-D /B-72 |
455*405*150 |
72 |
|
| KWMSB-D /A-24A |
350*350*80 |
24 |
The case body is made of cold rolled steel sheet,
electrostatic spraying, wall mounting, provide 12-24 adaptors,
available for SC\ST\LC |
| KWMSB-D /C-FC12 |
350*300*80 |
12 |
|
| KWMSB-D /C-SC12 |
|
|
|
| KWMSB-D /D-FC24 |
|
24 |
|
| KWMSB-D /D-SC24 |
|
|
|
Packing information
| type |
Products dimension(mm) |
Products |
Package dimension for out side carton (mm) |
No of units per carton(pcs) |
Total weight(kg) |
| |
|
weight(kg) |
|
|
|
| KWMSB-D /A-24 |
480*430*110 |
7 |
500*450*490 |
4 |
29 |
| KWMSB-D /A-48 |
480*430*150 |
8 |
|
3 |
25 |
| KWMSB-D / A-72 |
480*430*180 |
9 |
500*450*390 |
2 |
19 |
| KWMSB-D / B-48 |
480*430*150 |
8.5 |
500*450*490 |
3 |
26.5 |
| KWMSB-D / B-72 |
480*430*180 |
9.5 |
500*450*390 |
2 |
20 |
| KWMSB-D /A-24A |
385*385*115 |
3.85 |
405*405*605 |
4 |
20.5 |
| KWMSB-C-FC12 |
385*335*115 |
3.6 |
405*355*605 |
|
19 |
| KWMSB-DC-SC12 |
|
|
|
|
|
| KWMSB-DD-FC12 |
|
|
|
|
|
| KWMSB-D-SC12 |
|
|
|
|
|
|
|
|
KWMSB-A
12-48fiber |
KWMSB-L
8 fibers |
|
|
 |
KWMSB-L
Serials Fiber Terminal Box can be applied in the straight through
and branch connection of indoor optical cables, available for the
distribution and terminal connection of various optical fiber system
,fit for wall mounting
Order Guide
| Type |
Dimension |
Max Capacity (cores) |
remark |
| KWMSB-L-FC8 |
260*140*40 |
8 |
The body is made from cold rolled steel sheet, and the
surface use the technique of electrostatic spraying,8 outlets
for adaptors, Available for FC,SC,ST |
| KWMSB-L-SC8 |
260*140*40 |
8 |
|
| KWMSB-L-ST8 |
260*140*40 |
8 |
|
| KWMSB-L-CQ8 |
260*120*40 |
8 |
The body is made from cold rolled steel sheet, and the
surface use the technique of electrostatic spraying,8 outlets
for fiber pigtail |
Pack information
| Model |
inner carton dimension |
Inner carton |
out carton dimension(mm) |
No of units per carton(pcs) |
Total weight(kg) |
| |
|
weight(kg) |
|
|
|
| KWMSB-L |
320*150*60 |
1.05 |
630*330*340 |
20 |
21 |
| KWMSB-L-CQ |
320*150*60 |
1 |
630*330*340 |
20 |
21 |
|
|
|
