Our range of Fiber optical Cables is widely used
in industrial plants, office buildings, and electric utility companies.
Available in various specifications, our range is cost appropriate and
cost effective means of communication signal transmission. Our range
needs no maintenance and gives high resistance to electromagnetic noise
such as motors, radios, and other nearby cables.
LC
To LC Fiber Optic Patch Cable |
 |
 |
 |
We
supply the LC to LC 10Gigabit OM3 multi mode fiber optic cable that
can transmit 10G signal. Hui hong Techs 10Gig fiber optic patch
cables are designed to meet this requirement ,these LC-LC 10g duplex
fiber optic patch cords are with aqua OM3 50/125 fiber glass and
they are typically used in 10 Gigabyte Ethernet,our 10gigabit fiber
optic patch cables the bandwidth supported is as specified
IEEE802.3z which is for gig bit Ethernet. Hui hong Tech duplex10gig
fiber optic patch cords are manufactured according to TIA-492AAAC-A
standard for OM3 cable ,and the typical cable color is as per aqua
standard which was developed by Lucent technologies Applications
- Support 10 Gigabit data transmitting rates
- Connectors are with UPC polish
- Ceramic ferrules provide alignment
- OM3 50/125 fiber optic glass
- Used to connect patch panels and/or network devices that
require 50/125 multimode cable.
- Fully compliant with international industry standard
- Fulfill high bandwidth needs
- Use with LED and VCSEL laser light sources
LC is the short form of Lucent Connector,it is a push
and latch structure, with plastic housing and accurate 1.25mm
ceramic ferrule. LC connector is a popular kind of small form
connector which reduce the space and it is widely used for densely
installation.LC patch cable is with LC connectors. |
 |
|
Multimode
SC To SC Fiber Optic Patch Cable |
|
We
supply the SC to SC 10Gigabit OM3 multi mode fiber optic cable that
can transmit 10G signal. Hui hong Techs 10Gig fiber optic patch
cables are designed to meet this requirement ,these SC-SC 10g duplex
fiber optic patch cords are with aqua OM3 50/125 fiber glass and
they are typically used in 10 Gigabyte Ethernet,our 10gigabit fiber
optic patch cables the bandwidth supported is as specified
IEEE802.3z which is for gig bit Ethernet. Hui hong Tech duplex10gig
fiber optic patch cords are manufactured according to TIA-492AAAC-A
standard for OM3 cable ,and the typical cable color is as per aqua
standard which was developed by Lucent technologies Features
- Support 10 Gigabyte data transmitting rates
- Connectors are with UPC polish
- Ceramic ferrules provide alignment
- OM3 50/125 fiber optic glass
- Used to connect patch panels and/or network devices that
require 50/125 multi mode cable.
- Fully compliant with international industry standard
SC-SC 10Gig OM3 Multi mode duplex fiber optic patch cable
application Telecommunications & Data communications
LAN(including FTTH and FTTD) Component termination CATV, Ethernet
Network, WAN The SC fiber patch cord is with SC connector
which was invented by NTT. It is widely used fiber optic patch
cables. SC fiber optic patch cable has low cost and good durability,
SC fiber optic patch cables is with a locking tab on the cable
termination, it is a push and pull type optical connector. |
 |
|
Multimode
ST To ST Fiber Optic Patch Cable |
|
|
 |
We
supply the ST to ST 10Gigabit OM3 multi mode fiber optic cable that
can transmit 10G signal. Hui hong Techs 10Gig fiber optic patch
cables are designed to meet this requirement ,these ST-ST 10g duplex
fiber optic patch cords are with aqua OM3 50/125 fiber glass and
they are typically used in 10 Gigabyte Ethernet,our 10gigabit fiber
optic patch cables the bandwidth supported is as specified
IEEE802.3z which is for gig bit Ethernet. Hui hong Tech duplex10gig
fiber optic patch cords are manufactured according to TIA-492AAAC-A
standard for OM3 cable ,and the typical cable color is as per aqua
standard which was developed by Lucent technologies Features:
- Support 10 Gigabyte data transmitting rates
- Connectors are with UPC polish
- Ceramic ferrules provide alignment
- OM3 50/125 fiber optic glass
- Fully compliant with international industry standard
- Fulfill high bandwidth needs
- Use with LED and VCSEL laser light sources
- Backward compatible with LED-based 50/125 multi mode fiber
applications
- Cable Coating: PVC, Riser OFNR, or PLENUM CMP (OFNP)
- Cable Color: Aqua
- Every piece patch cable is tested during prodution
ST-ST 10Gig OM3 Multimode duplex fiber optic patch cable
application Telecommunications & Data communications
LAN(including FTTH and FTTD) Component termination CATV, Ethernet
Network, WAN ST fiber optic patch cables is with ST
connector which was developed by AT&T. |
|
|
Outdoor
Fiber Optic Cable |
|
- GYTS Fiber Optic Cable (Aerial and Duct)
- GYTA Fiber Optic Cable (Aerial and Duct)
- GYXTW Fiber Optic Cable (Aerial and Duct)
- GYTA53 Fiber Optic Cable (Direct buried)
- GYTY53 Fiber Optic Cable (Direct buried)
- GYTC8S Fiber Optic Cable (Aerial)
- GYFTY Fiber Optic Cable (Non-metallic)
- GYTA33 Fiber Optic Cable (Underwater or Direct buried)
- GYDTS Fiber Optic Cable (Aerial and Duct)
- GYDTA Fiber Optic Cable (Aerial and Duct)
- GYDXTW Fiber Optic Cable (Aerial and Duct)
- GYXTC8S Fiber Optic Cable (Aerial)
Outdoor fiber optic cables are made to protect the optical
fiber to operate safely in complicated outdoor environment. Most
outdoor fiber cables are loose buffer design, with the strengthen
member in the middle of the whole cable, the loose tubes surround
the central strength member. Inside the loose tube there is
waterproof gel filled, whole cable materials used and gels inside
cable between the different components (not only inside loose tube)
will help make the whole cable resist of water. Typical
outdoor fiber optic cable types are GYTS, GYTA, GYXTW, GYTA53,
GYTY53 and GYTC8S (also called Figure 8 cable) GYTS, GYTA and GYXTW
outdoor fiber cables are used for aerial and duct applications,
GYTA53 and GYTY53 are used for direct buried, GYTC8S the figure 8
outdoor fiber optic cable is used mainly for aerial. We supply
various kinds outdoor use fiber cables including both armored type
and not armored type; these cables are competitive on prices and
fast delivery. |
 |
|
Indoor
Fiber Optic Cable |
|
|
 |
With
the fast development of fiber optic communication technology and the
trend of FTTX, indoor fiber optic cables are more and more required
to be installed between and inside buildings. Typical indoor fiber
optic cable types include GJFJV, GJFJZY, GJFJBV, GJFJBZY, GJFDBV and
GJFDBZY. Compared with outdoor use fiber cable, indoor fiber optic
cable experience less temperature and mechanical stress, but they
have to be fire retardant, emit a low level of smoke in case of
burning. And indoor fiber cables allow a small bend radius to make
them be amendable to vertical installation and handle easily. Most
indoor fiber optic cables are tight buffer design, usually they
consist of the following components inside the cable, the FRP which
is non-metallic strengthen member, the tight buffer optical fiber,
the Kevlar which is used to further strength the cable structure,
making it resist high tension, and the cable outer jacket. The trend
is to use LSZH or other RoHS compliant PVC materials to make the
cable jacket; this will help protect the environment and the health
of the end users. Usually the single mode indoor fiber optic cables
are installed between the buildings where the distance is more than
100 meters, while multimode indoor fiber optic cables are used
shorter distance connections. We supply SMF and MMF indoor fiber
cables with various structures for different applications. We
offer:
- Single Core Round Tight Buffered Indoor Fiber Optic Cable
- Single Core Round Loose Tube Indoor Fiber Optic Cable
- Single Core Flat Tight Buffered Under Carpet Indoor Fiber
Optic Cable
- Double Core Flat Tight Buffered Indoor Fiber Optic Cable I
- Double Core Flat Tight Buffered Indoor Fiber Optic Cable II
- Double Core Flat Loose Tube Indoor Fiber Optic Cable
- Double Core Round Tight Buffered Indoor Fiber Optic Cable I
- Double Core Round Tight Buffered Indoor Fiber Optic Cable II
- Double Core Round Loose Tube Indoor Fiber Optic Cable I
- Double Core Round Loose Tube Indoor Fiber Optic Cable II
- Double Core Flat Tight Buffered Under Carpet Indoor Fiber
Optic Cable I
- Double Core Flat Tight Buffered Under Carpet Indoor Fiber
Optic Cable II
- Multi-Core Round Tight Buffered Distribution Indoor Fiber
Optic Cable I
- Multi-Core Round Tight Buffered Distribution Indoor Fiber
Optic Cable II
- Multi-Core Round Tight Buffered Distribution Indoor Fiber
Optic Cable III
- Multi-Core Round Tight Buffered Distribution Indoor Fiber
Optic Cable IV
- Multi-Core Round Breakout Indoor Fiber Optic Cable I
- Multi-Core Round Breakout Indoor Fiber Optic Cable II
- Multi-Core Round Breakout Indoor Fiber Optic Cable III
- Multi-Core Round Tight Buffered Distribution Indoor Fiber
Optic Cable III
- Multi-Core Flat Fiber Optic Ribbon Cable I
- Multi-Core Flat Fiber Optic Ribbon Cable II
- Multi-Core Flat Fiber Optic Ribbon Cable III
|
|
|
